Application of 5000 Series-9000 Series Aluminum Plate

5××× series

5××× series aluminum sheet: represents 5052, 5005, 5083, 5A05 series. 5××× series aluminum plate belongs to the more commonly used alloy aluminum plate series, the main element is magnesium, and the magnesium content is between 3-5%. Also known as aluminum-magnesium alloy. The main features are low density, high tensile strength and high elongation. In the same area, the weight of aluminum-magnesium alloy is lower than that of other series. Therefore, it is often used in aviation, such as aircraft fuel tanks. It is also widely used in conventional industries. The processing technology is continuous casting and rolling, which belongs to the series of hot-rolled aluminum plates, so it can be deep-processed by oxidation. In my country, the 5××× series aluminum plate belongs to one of the more mature aluminum plate series.

5××× series aluminum plate function:

5005 Similar to 3003 alloy, 5005 aluminum sheet has medium strength and good corrosion resistance. Often used as conductors, cookware, instrument panels, shells and architectural trim. The anodized film is brighter than the oxide film on the 3003 alloy and harmonizes with the tone of the 6063 alloy.

5050 aluminum plate can be used in thin plates as inner linings of refrigerators and refrigerators, automobile gas pipes, oil pipes and agricultural irrigation pipes; it can also be processed into thick plates, pipes, bars, special-shaped materials and wires.

5052 aluminum sheet has good forming performance, corrosion resistance, candleability, fatigue strength and moderate static strength. It is often used in the manufacture of aircraft fuel tanks, oil pipes, and sheet metal parts of transportation vehicles and ships, instruments, street lamp brackets and Rivets, hardware products, etc. 5056 aluminum plate is used in magnesium alloy and cable sheath rivets, zippers, nails, etc.; aluminum-coated wires are widely used in processing agricultural insect trap covers and other occasions where high corrosion resistance is required.

5083 aluminum sheet is often used in occasions requiring high corrosion resistance, good weldability and medium strength, such as welding parts of ships, automobiles and aircraft; pressure vessels, refrigeration devices, TV towers, drilling equipment that require strict fire protection , transportation equipment, missile elements, armor, etc.

5086 aluminum sheet is used in occasions requiring high corrosion resistance, good weldability and medium strength, such as ships, automobiles, aircraft, cryogenic equipment, TV towers, drilling equipment, transportation equipment, missile parts and decks, etc.

5154 aluminum sheet is used in welded structures, storage tanks, pressure vessels, ship structures and offshore facilities, and transportation tanks.

5182 aluminum sheet is used in thin sheets for processing can lids, auto body panels, control panels, reinforcements, brackets and other components.

5252 aluminum sheet is used in the manufacture of decorative parts with high strength, such as decorative parts for automobiles. It has a bright and transparent oxide film after anodization.

5254 aluminum plate is used in hydrogen peroxide and other chemical product containers.

5356 aluminum plate is used for welding aluminum-magnesium alloy electrodes and wires with magnesium content greater than 3%.

5454 aluminum sheet is used in welded structures, pressure vessels, and pipelines in marine facilities.

5456 aluminum plate is used in armor plate, high-strength welded structure, storage tank, pressure vessel, marine material.

5457 aluminum sheet is used in polished and anodized trim parts for automobiles and other equipment.

5652 aluminum plate is used in storage containers for hydrogen peroxide and other chemical products.

5657 aluminum sheet is used in polished and anodized trim parts for automobiles and other equipment, but in any case it must be ensured that the material has a fine grain structure.

5754 aluminum sheet is widely used in welded structures, storage tanks, pressure vessels, ship structures and offshore facilities, transportation tanks, and for applications requiring excellent processability, excellent corrosion resistance, high fatigue strength, high weldability and moderate static strength. the occasion.

5A02 aluminum sheet is used in aircraft fuel tanks and conduits, welding wires, rivets, and ship structural parts.

5A03 aluminum plate is used in medium-strength welded structures, cold stamping parts, welding vessels, and welding wires, and can be used to replace 5A02 alloy.

5A05 aluminum plate is used in welded structural parts, aircraft skin skeleton.

5A06 aluminum plate is used in welded structures, cold forged parts, welded and drawn container stress parts, and aircraft skin and bone parts.

5A12 aluminum plate is used in welded structural parts and bulletproof decks.

6××× series

6××× series aluminum sheet: represents 6061. It mainly contains magnesium and silicon, so it combines the advantages of 4××× series and 5××× series. 6061 is a cold-treated aluminum forging product, which is suitable for applications with high requirements on corrosion resistance and oxidation resistance. Good usability, excellent interface characteristics, easy coating, and good workability. Can be used on low voltage weapons and aircraft joints.

6××× series aluminum plate function:

6005 aluminum sheet is used in extruded profiles and pipes, and is also commonly used in structural parts that require strength greater than 6063 alloy, such as ladders, TV antennas, etc.

6009 aluminum sheet is used in automotive body panels.

6010 aluminum plate is used in thin plate, automobile body.

6061 aluminum plate has excellent interface characteristics, easy coating, high strength, good workability and strong corrosion resistance. Various industrial structures requiring certain strength, weldability and high corrosion resistance, such as aircraft parts, camera parts, couplers, marine accessories and hardware, electronic accessories and joints, decorative or various hardware, hinge heads, Magnetic heads, brake pistons, hydraulic pistons, electrical accessories, valves and valve parts.

6063 aluminum sheet is commonly used in building profiles, irrigation pipes and extruded materials for vehicles, benches, furniture, fences, etc.

6066 aluminum aluminum plate is used in forgings and welded structural extrusion materials.

6070 aluminum sheet is used in extruded materials and pipes for heavy duty welded structures and the automotive industry.

6101 aluminum plate is used in high-strength bars for buses, electrical conductors and radiator materials, etc.

6151 aluminum plate is used for die forging crankshaft parts, machine parts and production of rolling rings, which are required to have good forgeability, high strength and good corrosion resistance.

6201 aluminum plate is used in high-strength conductive rods and wires.

6205 aluminum sheet is used in thick plates, pedals and high impact extrusions.

6262 aluminum sheet is used for threaded, high-stress parts that require better corrosion resistance than 2011 and 2017 alloys.

6351 aluminum sheet is used in extruded structural parts of vehicles, pipelines for water, oil, etc.

6463 aluminum sheet is used in construction and various appliance profiles, as well as automotive trim parts with a bright surface after anodizing.

6A02 aluminum plate is used in aircraft engine parts, forgings and die forgings with complex shapes.

7××× series

7××× series aluminum sheet: represents 7075. Mainly contains zinc. It also belongs to the aviation series. It is an aluminum-magnesium-zinc-copper alloy, a heat-treatable alloy, and a super-hard aluminum alloy with good wear resistance. The 7075 aluminum plate is stress-relieved and will not be deformed or warped after processing. All 7075 aluminum plates are ultrasonically detected, which can ensure no blisters and impurities. The high thermal conductivity of 7075 aluminum plates can shorten the molding time and improve work efficiency. The main feature is that the hardness is high. 7075 is an aluminum alloy with high hardness and high strength, which is often used in the manufacture of aircraft.

2. Function of 7××× series grade aluminum sheet:

7005 aluminum sheet extrusion material is often used in the manufacture of welded structures that have both high strength and high fracture toughness, such as trusses, rods, containers of transportation vehicles; large heat exchangers, and can not be welded after welding. Melt-treated parts; also used to make sports equipment such as tennis rackets and softball bats.

7039 aluminum plate is used in refrigeration containers, cryogenic equipment and storage boxes, fire pressure equipment, military equipment, armor plates, and missile devices.

7049 aluminum plate is used for forging parts that have the same static strength as 7079-T6 alloy but require high resistance to stress corrosion cracking, such as aircraft and missile parts - landing gear hydraulic cylinders and extrusions. The fatigue properties of the parts are roughly equal to those of the 7075-T6 alloy, while the toughness is slightly higher.

7050 aluminum plate is used in medium and heavy plates, extrusions, free forgings and die forgings for aircraft structural parts. Manufacture of such parts to alloys the requirements are: high resistance to exfoliation corrosion, stress corrosion cracking, fracture toughness and fatigue resistance.

7072 aluminum sheet is used in air conditioner aluminum foil and ultra-thin strip.

7075 aluminum sheet is used in 7075 aluminum sheet for the manufacture of aircraft structures and futures. He requires high-strength structural parts and mold manufacturing with high strength and strong corrosion resistance.

7175 aluminum sheet is used for high-strength structures used in forging aircraft. T736 material has good comprehensive properties, that is, high strength, resistance to exfoliation corrosion and stress corrosion cracking, fracture toughness, and fatigue strength.

7178 aluminum sheet is used for parts that require high compressive yield strength for the manufacture of aerospace vehicles.

7475 aluminum sheet is used in aluminum-clad and non-aluminum-clad sheets for fuselage, wing frames, stringers, etc. Other parts that have both high strength and high fracture toughness.

7A04 aluminum sheet is used in aircraft skins, screws, and stress components such as girder stringers, bulkheads, ribs, landing gear, etc.

8××× series

8××× series aluminum sheet: 8011 aluminum sheet is more commonly used, which belongs to other series. It is an aluminum plate with the main function of making bottle caps, and is also used in radiators, most of which are used as aluminum foil. It is a less commonly used series in business.

9××× series

The 9××× series aluminum sheet belongs to the spare series, and the technology is so developed. In order to cope with the appearance of aluminum sheets containing other alloying elements, the International Aluminum Plate Generation Federation has specially indicated that the 9000 series is the spare series, waiting for another new variety to appear to fill the 9000. Series of blanks.
